Yuli photoelectric ob-sided sib tsoo tshuab thiab sib tsoo disc

Dec 26, 2023

Khoom zoo:

1, lub converter zaus nrog zaus hloov lub cev muaj zog tsav, kom ua tiav muag muag, muag muag, ceev stability, me me;

2, kev siv ob lub cev muaj zog tsav, sab sauv thiab qis sib tsoo disc thiab lub nplhaib sab hauv los ntawm lub cev muaj zog tsav, zaus tswj. Lub hnub lub log yog tsav los ntawm ib tug thib ob lub cev muaj zog zaus hloov dua siab tshiab kev tswj, qhov ceev hloov ntau yam yog wider, kev ua hauj lwm ceev piv yuav raug tswj tam sim ntawd thiab raug, thiab yuav hloov mus rau qhov yuav tsum tau ntawm sib txawv txheej txheem sib tsoo;

3. Lub hnub lub log thiab lub nplhaib sab hauv yog lifted synchronously kom tau raws li qhov yuav tsum tau noj thiab tso tawm workpieces thiab kho qhov meshing txoj hauj lwm ntawm lub nkoj nkoj;

4. Lub sab sauv thiab sab sib tsoo disc yog tsav los ntawm helical iav, uas txhim kho qhov smoothness ntawm kev ua haujlwm;

5, PLC tswj, siab siv hluav taws xob - roj proportional valve kaw-loop tawm tswv yim tswj, siab theem teeb tsa yooj yim dua thiab raug, yooj yim rau kev khiav lag luam, txhim khu kev qha thiab ruaj khov ua haujlwm;

6, lub tshuab daim ntawv thov txiv neej-tshuab interface (PT) zaub thiab PLC tswj, ntawm ib sab tes tso saib cov kev khiav hauj lwm tsis, ntawm qhov tod tes los ntawm nws kov hloov kho cov txheej txheem tsis, lub ntsiab ua hauj lwm yog ua tiav los ntawm lub zoo tib yam khawm;

7, cov duab thiab cov qauv sab hauv siab xav txog qhov yooj yim ntawm kev ua haujlwm thiab kev saib xyuas.

Technical parameters:

1. Sib tsoo disc specification: φ1136 × φ354 × 50mm

2. Kev sib tsoo siab tshaj plaws: φ350mm

3. Cruise nkoj tsis: British DP12 Z-200

4. Yam tsawg kawg nkaus sib tsoo thickness: 0.3mm

5. Qhov siab tshaj plaws sib tsoo thickness: 30mm

6. Lub cev muaj zog: 11kw

7, hnub ci tsav lub cev muaj zog: 1.5kw

8. Tsawg sib tsoo disc ceev: 0-50rpm

9, nqa lub cev muaj zog: 0.75kw

Xuab zeb twj tso kua mis lub cev muaj zog: 0.37kw
